Face Mask Detection Using Intel OpenVINO And OpenCV.

post image


The Story

Alt text

As more and more COVID-19 cases are reported each day and South Africa’s lock down restrictions have been loosen, we will be seeing an increase on the number of cases due to the lack of social distancing and the usage of facial masks.

In this post, I will walk you through the processes of creating a Face Mask Detector application using pre-trained models and Intel OpenVINO toolkit with OpenCV. This application can be improved and then integrated with CCTV or other types of cameras to detect and identify people without masks in public areas such as shopping centres and etc. The application could be useful in controlling the spread of the ever-increasing COVID-19 virus.


TL;DR

This project uses pre-trained models with OpenVINO toolkit and code can be found here

The How

Using the OpenVINO async API we can improve the overall frame-rate of the application, because rather than to wait for inference to complete, the application can continue operating on the host while the CPU is busy.

This walk-through executes 2 parallel inference requests for the Face Mask Detection and Face Detection networks that run simultaneously.

Using a set of the following pre-trained models:

  • face-detection-adas-0001, which is a primary detection network for finding faces.
  • face-mask-detection, which is a pre-trained model for detecting a mask.

The Walk-through

Alt text

Face Mask Detection application uses Deep Learning/Machine Learning to recognize if a user is not wearing a mask and issues an alert as shown in the image below.

Screenshot from 2020-06-01 22-21-47

Code walk-through

Watch the complete tutorial and code walk-through. Positive and building comments will be appreciated

The code which contains voice alert.

#!/usr/bin/env python3

import time
import os

from argparse import ArgumentParser

import cv2
import numpy as np
from responsive_voice.voices import UKEnglishMale


from inference import Network

engine = UKEnglishMale()
mp3_file = engine.get_mp3("Please wear your MASK!!")


def arg_parser():
    """Parse command line arguments.

    :return: command line arguments
    """
    parser = ArgumentParser()
    parser.add_argument(
        "-f",
        "--face-model",
        required=True,
        type=str,
        help="Path to an xml file with a trained model.",
    )
    parser.add_argument(
        "-m",
        "--mask-model",
        required=True,
        type=str,
        help="Path to an xml file with a trained model.",
    )
    parser.add_argument(
        "-i",
        "--input",
        required=True,
        type=str,
        help="Path to image or video file or 'cam' for Webcam.",
    )

    parser.add_argument(
        "-d",
        "--device",
        type=str,
        default="CPU",
        help="Specify the target device to infer on: "
        "CPU, GPU, FPGA or MYRIAD is acceptable. Sample "
        "will look for a suitable plugin for device "
        "specified (CPU by default)",
    )
    parser.add_argument(
        "-pt",
        "--prob_threshold",
        type=float,
        default=0.8,
        help="Probability threshold for detections filtering" "(0.8 by default)",
    )
    parser.add_argument(
        "--out", action="store_true", help="Write video to file.",
    )
    parser.add_argument(
        "--ffmpeg", action="store_true", help="Flush video to FFMPEG.",
    )
    parser.add_argument(
        "--debug", action="store_true", help="Show output on screen [debugging].",
    )

    return parser.parse_args()


def draw_boxes(frame, f_result, m_result, count, prob_threshold, width, height):
    """Draw bounding boxes onto the frame."""
    loc = 20
    for box in f_result[0][0]:  # Output shape is 1x1x100x7
        conf = box[2]
        if conf >= prob_threshold:
            xmin = int(box[3] * width)
            ymin = int(box[4] * height)
            xmax = int(box[5] * width)
            ymax = int(box[6] * height)
            _y = ymax + loc if ymax + loc > loc else ymax - loc

            detected_threshold = round(float(m_result.flatten()), 3)
            if detected_threshold > 0.3:
                label = ("Mask", (0, 255, 0))  # Color format: BGR
            else:
                label = ("No Mask", (0, 0, 255))
                if int(count) % 200 == 1:
                    engine.play_mp3(mp3_file)
            cv2.rectangle(frame, (xmin, ymin), (xmax, ymax), label[1], 1)
            cv2.putText(
                frame,
                f"{label[0]}: {detected_threshold :.2f}%",
                (xmin - 2 * loc, _y),
                cv2.FONT_HERSHEY_SIMPLEX,
                fontScale=0.5,
                color=label[1],
                thickness=2,
            )
    return frame


def process_frame(frame, height, width):
    """Helper function for processing frame"""
    p_frame = cv2.resize(frame, (width, height))
    # Change data layout from HWC to CHW
    p_frame = p_frame.transpose((2, 0, 1))
    p_frame = p_frame.reshape(1, *p_frame.shape)
    return p_frame


def infer_on_stream(args):
    """
    Initialize the inference network, stream video to network,
    and output stats and video.

    :param args: Command line arguments parsed by `build_argparser()`
    :param client: MQTT client
    :return: None
    """
    # Initialise the class
    face_infer_network = Network()
    mask_infer_network = Network()
    # Set Probability threshold for detections
    prob_threshold = args.prob_threshold

    try:
        mask_infer_network.load_model(
            model_xml=args.mask_model,
            device=args.device,
        )
        face_infer_network.load_model(
            model_xml=args.face_model,
            device=args.device,
        )
    except Exception:
        raise

    if args.input.lower() == "cam":
        video_file = 0
    else:
        video_file = args.input
        assert os.path.isfile(video_file)

    stream = cv2.VideoCapture(video_file)
    stream.open(video_file)

    # Grab the shape of the input
    orig_width = int(stream.get(3))
    orig_height = int(stream.get(4))
    average_infer_time = []

    _, _, input_height, input_width = face_infer_network.get_input_shape()
    _, _, mask_input_height, mask_input_width = mask_infer_network.get_input_shape()

    if not stream.isOpened():
        msg = "Cannot open video source!!!"
        raise RuntimeError(msg)
    count = 0

    while stream.isOpened():
        # Grab the next stream.
        (grabbed, frame) = stream.read()
        # If the frame was not grabbed, then we might have reached end of steam,
        # then break
        if not grabbed:
            break

        count += 1
        p_frame = process_frame(frame, input_height, input_width)
        m_frame = process_frame(frame, mask_input_height, mask_input_width)

        start_infer = time.time()
        face_infer_network.exec_net(p_frame)
        mask_infer_network.exec_net(m_frame)
        if face_infer_network.wait() == 0 and mask_infer_network.wait() == 0:
            f_result = face_infer_network.get_output()
            m_result = mask_infer_network.get_output()
            end_infer = time.time() - start_infer
            average_infer_time.append(end_infer)
            message = f"Inference time: {end_infer*1000:.2f}ms"
            cv2.putText(
                frame, message, (20, 20), cv2.FONT_HERSHEY_COMPLEX, 0.5, (0, 0, 0), 1
            )

            # Draw the boxes onto the input
            out_frame = draw_boxes(
                frame,
                f_result,
                m_result,
                count,
                prob_threshold,
                orig_width,
                orig_height,
            )

        if args.debug:
            cv2.imshow("Frame", frame)

        key = cv2.waitKey(1) & 0xFF

        # # if the `q` key was pressed, break from the loop
        if key == ord("q"):
            break

    # Release the out writer, capture, and destroy any OpenCV windows
    stream.release()
    cv2.destroyAllWindows()

if __name__ == "__main__":
    # Grab command line args
    args = arg_parser()
    # Perform inference on the input stream
    infer_on_stream(args)

Running the application

Alt text

  • Download the docker images with a pre-installed version of OpenVINO 2020.2
    docker pull mmphego/intel-openvino

  • Download the facemask detection model.
    wget https://github.com/didi/maskdetection/raw/master/model/face_mask.caffemodel
    wget https://raw.githubusercontent.com/didi/maskdetection/master/model/deploy.prototxt

  • Convert model to OpenVINO’s Intermediate Representations (IR) using the Model Optimizer, which will produce .xml and .bin files.
    docker run --rm -ti \
    --volume "$PWD":/app \
    --env DISPLAY=$DISPLAY \
    --volume="/tmp/.X11-unix:/tmp/.X11-unix:rw" \
    mmphego/intel-openvino \
    bash -c "/opt/intel/openvino/deployment_tools/model_optimizer/mo.py \
      --framework caffe \
      --input_model face_mask.caffemodel \
      --input_proto deploy.prototxt"

  • Download face detection model from the model zoo, which will produce .xml and .bin files.
    docker run --rm -ti \
    --volume "$PWD":/app \
    --env DISPLAY=$DISPLAY \
    --volume="/tmp/.X11-unix:/tmp/.X11-unix:rw" \
    mmphego/intel-openvino \
    bash -c "/opt/intel/openvino/deployment_tools/open_model_zoo/tools/downloader/downloader.py \
      --name face-detection-adas-0001 \
      --precision FP16"


Usage

xhost +;
docker run --rm -ti \
--volume "$PWD":/app \
--env DISPLAY=$DISPLAY \
--volume="/tmp/.X11-unix:/tmp/.X11-unix:rw" \
--device /dev/snd \
--device /dev/video0 \
mmphego/intel-openvino \
bash -c \
"source /opt/intel/openvino/bin/setupvars.sh && \
python main.py \
    --face-model models/face-detection-adas-0001.xml \
    --mask-model models/face_mask.xml \
    --debug \
    -i resources/mask.mp4"
xhost -;
  • --env DISPLAY=$DISPLAY: Enables GUI applications
  • --volume="/tmp/.X11-unix:/tmp/.X11-unix:rw": Enable GUI applications
  • --device /dev/snd: Enable sound from container
  • --device /dev/video0: Share webcam with container
